EVO WB760 IP: The Ultimate IP65 LED Wash Beam – Pixel Control, Infinite Rotation, and Tour-Ready Power

Meet the EVO WB760 IP, the next-generation wash beam that redefines creative potential in a compact, IP65-rated package. Engineered for the demands of touring, festivals, and high-end architectural lighting, this fixture combines the raw power of OSRAM LEDs, full pixel-by-pixel control, and game-changing infinite lens rotation—delivering an unprecedented FX toolkit in a lightweight 13 kg frame.


🎨 VIBRANT OUTPUT & SUPERIOR COLOR ENGINE


At the heart of the EVO WB760 IP is a hybrid light source designed for saturated colors, powerful beams, and stunning visual impact. The quality of OSRAM LEDs ensures superior performance and unmatched reliability.


• Main Light Source: 7 × 60W RGBW OSRAM LEDs for intense colors and a perfect white spectrum.

• Aura Effect: 28 × 0.5W RGB LEDs for creating mesmerizing "glow" effects and secondary graphic layers.

• Total Luminous Flux: 7,200 lumens of punchy, vibrant output for both wash and beam applications.

• Color Rendering Index (CRI): CRI 80 for natural and accurate color reproduction.

• LED Lifetime: 50,000 hours for long-term reliability and minimal maintenance.

• Color Control: Full RGBL color mixing, linear color temperature presets (2,000–8,000K), and individual control of every pixel.

🔀 DYNAMIC MOVEMENT & INFINITE ROTATION

The EVO WB760 IP is no ordinary wash light. Its continuous, bi-directional front lens rotation unlocks a world of dynamic aerial effects—from swirling vortexes to animated beams—previously impossible with standard fixtures.


• Pan/Tilt Movement: 540° Pan / 205° Tilt with 16-bit resolution for exceptionally smooth and precise positioning.

• Infinite Lens Rotation: Game-changing infinite and bi-directional rotation to create unique, eye-catching motion FX.

✨ VERSATILE OPTICS & ADVANCED FX

Shift from a razor-sharp 3.15° beam to a lush, even 45° wash in an instant. Leverage the dual-layer effect capabilities to program complex, high-impact looks that command attention.


• Motorized Zoom: A wide 3.15° to 45° range, perfect for tight mid-air effects and broad scenic washes.

• Pixel FX: Full pixel-mapping control over each of the 7 main LEDs to create custom patterns, shapes, and animations.

• Dimming & Strobe: 16-bit 0–100% electronic dimming with multiple curves and a variable-speed strobe.

🎛️​ PROFESSIONAL CONTROL & NETWORKING

• DMX512 | ArtNet | sACN | RDM – works flawlessly in complex networked environments

• Selectable DMX Channel Modes: 26 / 49 / 105 / 127

• Adjustable refresh rate (900 to 25,000 Hz) – ideal for flicker-free operation in TV & film

• Full-color LCD menu with 180° flip + intuitive 4-button touch panel

• Software upgrades via RJ45 – stay up to date without opening the fixture

🛡️ BUILT FOR ANY ENVIRONMENT

Rain, dust, humidity, or heat are no match for the EVO WB760 IP. Its rugged, fully sealed chassis guarantees consistent performance in any condition, making it the ideal workhorse for rental inventories and permanent installations.


• Protection Rating: IP65 certified for complete dust and water ingress protection.

• Reliability: Built to withstand the rigors of touring and harsh outdoor events.

• Dimensions & Weight: 210 × 309.5 × 463 mm | Only 13 kg.

• Power & Thermal: 700W max power consumption | 2387 BTU/hr thermal output.

🔥 WHY CHOOSE EVO WB760 IP?

 FEATURES                          EVO 1960 WB PIX IP                                 Typical IP LED Washes


🔋 LED  Source                                ✔ 60W RGBW OSRAM LEDs + RGB FX           ✘ Basic 19x40W

🎭 Pixel FX✔                                     ✔ Dedicated pixel LEDs                                       ✘ Limited or none

💧 IP65 on All Connectors            ✔ Full protection                                                   ✘ IP54 or partial sealing

🎛 DMX Modes + Art-Net/sACN     ✔ Advanced Mode                                                ✘ DMX base

🎥 Lens rotation                              ✔ Infinite lens rotation for motion FX             ✘ Fixed or standard rotation only

🔬 Zoom                                            ✔ 3.15° tight beam + 45° wide wash                 ✘ Limited zoom

​

THE IDEAL SOLUTION FOR:

• 🎵 Live Concerts & Touring: A compact, powerful, and reliable workhorse for any stage design.

• 🎭 Broadcast & TV Studios: Flicker-free operation and high-quality color rendering for the camera.

• 🏛️ Architectural Lighting: A robust, IP65-rated fixture perfect for permanent outdoor installations.

• 🎡 Corporate Events & Theme Parks: Unique visual effects to create immersive and memorable experiences.

•  🎛  Rental Houses: A highly versatile and durable fixture offering a rapid return on investment.
